SPECIFICATIONS
- Thermal Resolution
- 80×60
- Battery Life
- Approximately 1h
- Object Temperature Range
- -20°C — 120°C (–4°F — 248°F)
- Phone
- iOS
- Accuracy
- ±3°C or ±5%, typical Percent of the difference between ambient and scene temperature. Applicable 60s after start-up when the unit is within 15 °C – 35 °C and the scene is within 5 °C – 120 °C.
- Operating Temperature
- 0 °C – 35 °C (32°F – 95°F) , battery charging 0 °C – 30 °C (32°F – 86°F)
- Spot Meter
- One spot meter (centered).
IMAGING & OPTICAL
- Adjustable MSX distance
- 0.3m – Infinity
- Focus
- Fixed 15cm – Infinity
- Frame Rate
- 8.7Hz
- HFOV/VFOV
- 50° ± 1° / 38° ± 1°
- Palette
- Gray (white hot), Hottest, Coldest, Iron, Contrast, Arctic, Lava and Color Wheel
- Shutter
- Automatic/Manual
- Thermal Resolution
- 80×60
- Thermal Sensitivity [MRDT]
- 150mK
- Thermal Sensor
- Pixel size 17µm, 8 – 14µm spectral range
- Video and Still Image Display/Capture
- Saved as 1440×1080
- Visual Resolution
- 1440×1080
POWER
- Battery charge time
- 40 min
- Battery Life
- Approximately 1h
MEASUREMENT & ANALYSIS
- Accuracy
- ±3°C or ±5%, typical Percent of the difference between ambient and scene temperature. Applicable 60s after start-up when the unit is within 15 °C – 35 °C and the scene is within 5 °C – 120 °C.
- Object Temperature Range
- -20°C — 120°C (–4°F — 248°F)
- Spot Meter
- One spot meter (centered).
GENERAL
- Dimensions (H x W x D)
- 34 x 67 x 14mm (1.3 x 2.6 x 0.6in)
- Phone
- iOS
- Weight
- 34.5g
ENVIRONMENTAL & CERTIFICATIONS
- Certifications
- MFi (iOS version), RoHS, CE/FCC, CEC-BC, EN61233
- Drop test
- Drop from 1.5m
- Emissivity Settings
- Matte: 95%, Semi-Matte: 80%, Semi-Glossy: 60%, Glossy: 30% Reflected background temperature is 22°C
- Non-Operating Temperature
- -20 °C – 60 °C (-4°F – 140°F)
- Operating Temperature
- 0 °C – 35 °C (32°F – 95°F) , battery charging 0 °C – 30 °C (32°F – 86°F)
COMMUNICATION & DATA STORAGE
- Capture modes
- Video, Still image
- Charging
- Female USB-C (5V/1A)
- File Formats
- Still images – radiometric jpeg Video – MPEG-4 (file format MOV (iOS), MP4 (Android))
- Video
- Male Lightning (iOS), Male USB-C (Android)
