IMAGING & OPTICAL

Adjustable MSX distance

30 cm — Infinity

Focus

Fixed 30 cm — Infinity

Frame Rate

8.7 Hz

HFOV/VFOV

54° ±1° / 42° ±1°

Image Modes

Infrared, visual, MSX

Palette

Gray (white hot), Hottest, Coldest, Iron, Contrast, Arctic, Lava and Color Wheel

Shutter

Automatic/Manual

Thermal Resolution

160 × 120 (19,200 pixels)

Thermal Sensitivity/NETD

70 mK

Thermal Sensor

Pixel size 12 µm, 8 — 14 µm spectral range

Visual Resolution

640 × 480

VividIR

Yes

POWER

Battery charge time

60–90 min for fully charged
15 min charging, from empty battery, gives 40 min operating time

Battery Life

Approximately 1 hour 30 minutes

Charging Method

Female USB-C (5V/1A)

MEASUREMENT & ANALYSIS

Accuracy

±3°C (5.4°F) or ±5%. Applicable 60 sec after start-up when the unit is within 15°C to 35°C (59°F to 95°F) and the scene is within 5°C to 120°C (41°F to 248°F)

Measurement Corrections

Emissivity; Reflected apparent temperature (22°C / 72°F)

Object Temperature Range

-20°C — 120°C (–4°F — 248°F) and 0°C — 400°C (32°F — 752°F)

Spot Meter

Hottest, Coldest and 3 spot measurement

GENERAL

Battery charge monitor

0 — 100%

Clip Span

130 mm (min) / 195 mm (max)

Device Compatibility

iOS (version 15 and later) or Android (version 11 and later) smartphones and tablets

Dimensions (H x W x D)

37.5 mm × 35 mm × 149 mm (1.5 in × 1.4 in × 5.9 in)

Remote Operation

Up to 5 m (16.4 ft) from smart device via Wi-Fi

Weight

153 g (5.4 oz)

ENVIRONMENTAL & CERTIFICATIONS

Certifications

RoHS, CE/FCC, CEC-BC, EN62133, UL1642, WEEE 2012/19/EU, IP54

Drop test

Drop from 2 m (6.56 ft)

Emissivity Settings

Matte: 95%, Semi-Matte: 80%, Semi-Glossy: 60%, Glossy: 30%

Non-Operating Temperature

-40°C to 70°C (-40°F to 158°F)

Operating Temperature

-10°C to 50°C (14°F to 122°F), battery charging 0°C to 45°C (32°F to 113°F)

COMMUNICATION & DATA STORAGE

Bluetooth

Yes

Capture modes

Video, Still image

Charging

Female USB-C (5V/1A)

File Formats

Radiometric JPG, MPEG-4 (file format MOV (iOS), MP4 (Android))

WiFi

IEEE 802.11 a/b/g/n
